外形尺寸Dimensions

650*600*475mm

重量Weight

90KG

顯示方式Display

觸屏操作，中文顯示Chinese/English display，Touch screen

電源voltage

220V

功率Power

500W

切割長度Cutting Length

0.5mm-99999.99mm

前端剝皮長度Stripping Length

0.1-100mm

后端剝皮長度

0.1-20mm

剝線范圍Cutting Range

（1-25 mm2BV硬線折彎）自動調節線芯

(1-25 mm BV hard wire bending) automatic adjustment of the core

折彎次數

標準20次，；需增加可定制

Standard 20 times,(more than 20 times is optional)

折彎長度

長線模式末端留皮大于 55mm；

短線模式末端留皮10mm。

The skin at the end of long line mode is greater than 55mm;

In the short line mode, the end skin was retained for 10mm

折彎方式

順時針，逆時針，折彎程度可調，30°，45°，60°，90°,同一根線可同時折正反兩個彎。

Clockwise and counterclockwise, adjustable bending degree, 30 degrees, 45 degree, 60 degrees, 90 degrees. positive and negative two bending in one line

刀具材料

進口ASSAB17合金高速鋼

import  ASSAB17 alloy high speed steel

切割公差Cutting tolerance

Within 0.002 x Lmm ※ L=cutting length

導管直徑Max. wire diam

1-14mm

驅動方式Driving way

滾輪送線，八輪驅動，,獨立驅動盒驅動

Eeight-wheel drive,independent drive box driver

生產率（次／分）Productivity(pcs／m)

長線模式：700條；短線模式：850條

long wire mode: 700pcs；short wire mode:850pcs
